DGC 120

Call now

DGC 120

Product Usage

dry goods

general purpose

Main Features

Reusable Intermediate Bulk Containers (IBC’s) for dry goods.

Robust welded and galvanised steel frames.
Replaceable rotationally moulded seamless plastic liner.
Optional top inlets and bottom outlets.
Liner cone outlets of 60°, 90° and 120°.
Capacities from 500 – 2250 litres.

DGC’s are manufactured to provide users with tough long lasting dry goods containment and transportation capabilities. Frames last many years and the liners can be replaced when necessary. The cone angle on the liner can be selected to meet the flow requirements of the dry goods contents. We can advise on liner service life performance with a wide range of contents based on our extensive product performance database.

Industry Sectors

Speciality Chemicals

Animal Feeds

Bulk Foods

Cosmetics

Construction

back to all products

Description

The DGC is a reusable silo IBC designed for the transportation and storage of dry goods e.g. powders and granules.

The DGC liner is rotationally moulded in natural UV stabilised linear medium density polyethylene. The polymer has strong resistance to industrial wear and tear. The conical base has a 90°cone angle which is designed to provide total discharge of the contents. The liner is supported and protected by a galvanised mild steel frame, providing excellent resistance to the elements. The base of the frame has integral four way fork truck entry.

The liner inlet, which is 350mm in diameter, has a PP³ screw cap fitted with an EPDM² O-ring seal as standard. The vertical outlet at the base of the liner can be specified with a slide valve or iris valve to suit individual applications.

Dimensions

Width/Depth (mm)	1180/1180
Height (mm)	See product range
Inlet diameter (mm)	350
Outlet diameter (mm)	250
Tare weight (kg)	See product range
Nominal capacity (L)	See product range

Composition

Liner	LMDPE¹
Frame	Mild Steel (galvanised)
Screw cap lid	PP²
Screw cap seal	EPDM³
Outlet / Seal	Various (see options)

Options

460 mm clamp band lid

Iris or Slide valve outlet

Anti-tilt bars on frame

Full fork tunnels on frame (maximum handling stability)

Castors on frame

Venting / anti-vac / pressure relief

Vinyl logos

Trem card holders

Coloured liner, anti-static liner, semi-conductive liner, flame retardant liner

Linear Medium Density Polythylene
Polypropylene
Ethylene Propylene Diene Monomer

Dimensions subject to normal manufacturing tolerances.

Product Range

500

Capacity – L

500

Height – mm

1150

Tare Weight

750

Capacity – L

750

Height – mm

1370

Tare Weight

100

1000

Capacity – L

1000

Height – mm

1730

Tare Weight

115

1250

Capacity – L

1250

Height – mm

1870

Tare Weight

125

1500

Capacity – L

1500

Height – mm

2105

Tare Weight

135

1750

Capacity – L

1750

Height – mm

2327

Tare Weight

145

2000

Capacity – L

2000

Height – mm

2526

Tare Weight

160

2250

Capacity – L

2250

Height – mm

2739

Tare Weight

165

Options

More details on the options outlined below can be found by clicking on the Downloads tab and selecting the pdf you require.

Standard

Not Available

Optional

500

Outer Frame Composition

Galvanised Steel

Steel

Stainless Steel

Powder Coated Steel

Liner Composition

Natural LMDPE¹

Anti-static LMDPE¹

Black semi-conductive LMDPE¹

Flame retardant LMDPE¹

Closures

360mm (14”) Screw cap

460mm (18”) Clamp
band lid

360mm (14”) Arag lid

Valves

Slide valve

Iris valve

Top Fittings

Anti-vacuum vent (AV)

Pressure relief vent (PRV)

Combined AV and PRV

Handling

Anti-tilts in frame

Fork tunnels

Castors

Customisation

Coloured liner

Graphics on liner

750

Outer Frame Composition

Galvanised Steel

Steel

Stainless Steel

Powder Coated Steel

Liner Composition

Natural LMDPE¹

Anti-static LMDPE¹

Black semi-conductive LMDPE¹

Flame retardant LMDPE¹

Closures

360mm (14”) Screw cap

460mm (18”) Clamp
band lid

360mm (14”) Arag lid

Valves

Slide valve

Iris valve

Top Fittings

Anti-vacuum vent (AV)

Pressure relief vent (PRV)

Combined AV and PRV

Handling

Anti-tilts in frame

Fork tunnels

Castors

Customisation

Coloured liner

Graphics on liner

1000

Outer Frame Composition

Galvanised Steel

Steel

Stainless Steel

Powder Coated Steel

Liner Composition

Natural LMDPE¹

Anti-static LMDPE¹

Black semi-conductive LMDPE¹

Flame retardant LMDPE¹

Closures

360mm (14”) Screw cap

460mm (18”) Clamp
band lid

360mm (14”) Arag lid

Valves

Slide valve

Iris valve

Top Fittings

Anti-vacuum vent (AV)

Pressure relief vent (PRV)

Combined AV and PRV

Handling

Anti-tilts in frame

Fork tunnels

Castors

Customisation

Coloured liner

Graphics on liner

1250

Outer Frame Composition

Galvanised Steel

Steel

Stainless Steel

Powder Coated Steel

Liner Composition

Natural LMDPE¹

Anti-static LMDPE¹

Black semi-conductive LMDPE¹

Flame retardant LMDPE¹

Closures

360mm (14”) Screw cap

460mm (18”) Clamp
band lid

360mm (14”) Arag lid

Valves

Slide valve

Iris valve

Top Fittings

Anti-vacuum vent (AV)

Pressure relief vent (PRV)

Combined AV and PRV

Handling

Anti-tilts in frame

Fork tunnels

Castors

Customisation

Coloured liner

Graphics on liner

1500

Outer Frame Composition

Galvanised Steel

Steel

Stainless Steel

Powder Coated Steel

Liner Composition

Natural LMDPE¹

Anti-static LMDPE¹

Black semi-conductive LMDPE¹

Flame retardant LMDPE¹

Closures

360mm (14”) Screw cap

460mm (18”) Clamp
band lid

360mm (14”) Arag lid

Valves

Slide valve

Iris valve

Top Fittings

Anti-vacuum vent (AV)

Pressure relief vent (PRV)

Combined AV and PRV

Handling

Anti-tilts in frame

Fork tunnels

Castors

Customisation

Coloured liner

Graphics on liner

1750

Outer Frame Composition

Galvanised Steel

Steel

Stainless Steel

Powder Coated Steel

Liner Composition

Natural LMDPE¹

Anti-static LMDPE¹

Black semi-conductive LMDPE¹

Flame retardant LMDPE¹

Closures

360mm (14”) Screw cap

460mm (18”) Clamp
band lid

360mm (14”) Arag lid

Valves

Slide valve

Iris valve

Top Fittings

Anti-vacuum vent (AV)

Pressure relief vent (PRV)

Combined AV and PRV

Handling

Anti-tilts in frame

Fork tunnels

Castors

Customisation

Coloured liner

Graphics on liner

2000

Outer Frame Composition

Galvanised Steel

Steel

Stainless Steel

Powder Coated Steel

Liner Composition

Natural LMDPE¹

Anti-static LMDPE¹

Black semi-conductive LMDPE¹

Flame retardant LMDPE¹

Closures

360mm (14”) Screw cap

460mm (18”) Clamp
band lid

360mm (14”) Arag lid

Valves

Slide valve

Iris valve

Top Fittings

Anti-vacuum vent (AV)

Pressure relief vent (PRV)

Combined AV and PRV

Handling

Anti-tilts in frame

Fork tunnels

Castors

Customisation

Coloured liner

Graphics on liner

2250

Outer Frame Composition

Galvanised Steel

Steel

Stainless Steel

Powder Coated Steel

Liner Composition

Natural LMDPE¹

Anti-static LMDPE¹

Black semi-conductive LMDPE¹

Flame retardant LMDPE¹

Closures

360mm (14”) Screw cap

460mm (18”) Clamp
band lid

360mm (14”) Arag lid

Valves

Slide valve

Iris valve

Top Fittings

Anti-vacuum vent (AV)

Pressure relief vent (PRV)

Combined AV and PRV

Handling

Anti-tilts in frame

Fork tunnels

Castors

Customisation

Coloured liner

Graphics on liner
